Model：LSK-LCZ
Application: Used to perform thermal abuse (high-temperature) or thermal shock tests on lithium primary batteries and other primary batteries, as well as lithium-ion batteries (for digital electronic and medical products such as mobile phones, notebook computers, cameras, and medical instruments), Ni-MH, Ni-Cd, and lead-acid batteries (for products such as power tools and toys).
Application: Used to perform thermal abuse (high-temperature) or thermal shock tests on lithium primary batteries and other primary batteries, as well as lithium-ion batteries (for digital electronic and medical products such as mobile phones, notebook computers, cameras, and medical instruments), Ni-MH, Ni-Cd, and lead-acid batteries (for products such as power tools and toys).
Applicable to various types of single cells and battery packs, including lithium-ion, Ni-MH, Ni-Cd, lead-acid, and nickel metal hydride batteries. The equipment is used to perform thermal abuse (ultra-high temperature) and thermal shock tests in accordance with the following standards:
GB 8897.4-2002 (idt IEC 60086-4:2000) Primary batteries—Part 4: Safety of lithium batteries
GB 8897.5-2006 (idt IEC 60086-5:2005) Primary batteries—Part 5: Safety of batteries with aqueous electrolyte
IEC 62133:2002 Secondary cells and batteries containing alkaline or other non-acid electrolytes—Safety requirements for portable sealed secondary cells and batteries
IEC 61951-1:2003 Portable sealed rechargeable cells and batteries containing alkaline or other non-acid electrolytes—Part 1: Nickel-cadmium
IEC 61951-2:2003 Portable sealed rechargeable cells and batteries containing alkaline or other non-acid electrolytes—Part 2: Nickel-metal hydride
IEC 61960:2003 Secondary lithium cells and batteries for portable applications
UL 1642:2006 Lithium Batteries
| Item | Specification |
|---|---|
| Test chamber dimensions | 600 mm (W) × 600 mm (H) × 600 mm (D) |
| Test chamber volume | 216 L |
| Temperature range | RT + 20 °C to +200 °C |
| Temperature fluctuation | ±0.1 °C (at +100 °C); ±0.2 °C (at +200 °C) |
| Temperature uniformity (in chamber) | ±0.5 °C (at +100 °C); ±1.5 °C (at +200 °C) |
| Temperature ramp-up time | Ambient to +200 °C: < 50 min |
| Setting / display resolution | Temperature: 1 °C; Time: 1 min |
| Indication accuracy | Temperature: ±(2 °C + 1 digit) |
| Control mode | Program mode / Constant mode |
| Programmable temperature ramp rate (slope) | > 5 °C |
| Explosion-relief exhaust | Safety door for pressure relief in case of explosion inside the chamber |
